Specification :
Sensor Resolution : 640*480 CMOS
Symbologies 1D :
EAN-8,EAN-13,EAN-13 2 add-on, EAN-13 5 add-on,ISSN,ISBN,UPC-A,UPC-E,Code 39,Code 93,Code 128,Codabar,Industrial 2 of 5,Interleaved 2 of 5,Matrix 2 of 5, Standard 25,GS1 DataBar(RSS14), GS1 DataBar Limited,GS1 DataBar Expanded, ISBT-128,GS1-128,code39FULLASCII,Plessey,MSI Plessey
Symbologies 2D :
PDF417,Micro PDF417,QRcode,MicroQR,Datamatrix
Scanning Range Test Code :
UPC-13mil : Min. Range 1cm / Max. Range 8cm
Screen 1D : Min. Range 5cm / Max. Range 18cm
Screen 2D : Min. Range 5cm / Max. Range 30cm
Countries Keyboard : English, French, Italian, German, Spanish,Turkish (Q ), Belgian (French),Portuguese (Brazil),Portuguese (Portugal)
OS : Linux,Android,Windows XP, 7, 8,10,MacOS
Scan Mode : Auto scan
Min decode : Code 39 5mil
Decoded capability : 1D and 2D codes on printed paper and mobile screen
Min symbol contrast : 35%
Secondary Development : By serial command
Duration : Withstand drop from 1.5 meters 5 times
Sealing : IP54
Operating Temperature : 0-55℃
Storage Temperature : -20-60℃
Operating Humidity : 5-95% Non-condensed
Storage Temperature : 5-95% Non-condensed
Ambient Light : 0-70000LUX
Beeper : LED, BEEPER
Net Weight : 62g
Weight with package : USB:195g/RS232:270g
Host Size(L*W*H) : 49.3mm*49.3mm*30.1mm
Packing Size(L*W*H) : 185mm*101mm*52mm
Data line length : 180cm±3cm
Interface Type : USB, Serial Port (TTL, RS232, RS485), Wiegand
Operating Voltage : 5V
Support Interface : USB / Serial Port
Standby power : 107mA/0.535W
Operating Power : 126mA/0.63W
Max. Operating Power : 157mA/0.785W
